A4LD, 4R44E, 4R55E, 5R44E, 5R55E Automatic Transmission Lock Up Torque Converter
Diameter: 11"
Bolt Circle To Bolt Circle: 9.30"
Mount: 4 Pads, Offset, 3/8 x 24
Hub: Flats / Stepped
Pilot: Diameter 0.825" / Length 1.250"
Splines: 21
Stall: High
Codes: 1L5AB, 1L5AC, 1L5AD, 2L5AA, 2L5BD, 4L5AD, YL2AB, YL2BA
Some Ranger (3.0L) (2001-2003)
A4LD, 4R44E, 4R55E, 5R44E, 5R55E, 5R55N, 5R55S, 5R55W Automatic Transmission Lock Up Torque Converter Diameter: 11" Bolt Circle To Bolt Circle: 9.250" Mount: 4 Studs, 3/8 x 24 Hub: Flats /...
A4LD, 4R44E, 4R55E, 5R44E, 5R55E Automatic Transmission Lock Up Torque Converter Diameter: 11" Bolt Circle To Bolt Circle: 9.250" Mount: 4 Pads, Offset, 3/8 x 24 Hub: Flats / Stepped Pilot:...
A4LD Torque Converter, Lock Up, Codes 97HJC, BE, GA / Dia 11" / Bolt Circle 9.3" / Pads 4 Studs / Input Splines 21 / Low Stall / FM-65LS / 1987 - 1989 Merkur some 2.9L
A4LD Torque Converter, Lock Up, Codes CA, CE, DE / Dia 11" / Bolt Circle 9.3" / Pads 4 Studs / Input Splines 21 / Low Stall / FM-65 / 1987 - 1989 Merkur some 2.3L
ZF6HP26 Lock-Up Torque Converter Diameter: 11.125" Bolt Circle To Bolt Circle: 11.50" Mount: Mount Plate 3 Captive Nuts 10mm x 1.5 Hub: Slotted / Stepped Pilot: Diameter 1...
Honda Saturn, Mitsubishi F3A21 Automatic Transmission Torque Converter With Lock UpDiameter: 10.90"Bolt Circle To Bolt Circle: 8.750"Mount: 6 Pads 10mm x 1.25Hub: Flats / FlangedPilot: Diameter - 1...
AXOD, AXODE, AX4S, AX4N, 4F50N Automatic Transmission Lock-Up Torque Converter Diameter - Bolt Circle to Bolt Circle: 10.750" Bolt Circle To Bolt Circle: 8.875" Mount: 4 Studs 10mm x 1.0 Hub:...
5L40E, 5L50E Automatic Transmission Lock-Up Torque Converter Diameter: 10.250" Bolt Circle To Bolt Circle: 9.250" Mount: 3 Pads; 10mm x 1.5 Hub: Bushing Pilot: Diameter 1.257" Splines:...
Volvo Lock-Up Torque Converter Diameter: 11.560" Bolt Circle To Bolt Circle: 9.60" Mount: 6 Pads Square; 10mm x 1.25 Hub: Slotted Pilot: Diameter 0.824" Length: 1" Splines: 23 Stall:...
